Level Switches
NISAN direct insert or direct mounted level switches use a float, counterbalance and magnetic switch mechanism to actuate contacts as liquid level changes. Side-mounted and top-mounted versions are offered for direct insertion or with an external chamber/cage.
Design features
- A non-magnetic barrier tube effectively isolates the switch mechanisms from the controlled liquid.
- The tank/vessel connection must be located at the elevation where set level is to occur.
- Applications are suitable in cryogenic tanks and applications for high temperature with special material are also applicable
- This provides contact changeover at a selected elevation level in the tank / vessel.
- To improve reliability the stem guide isolated just above the float.
Technical specification
Build and limits
Taken from our published product data. Confirm against your line specification before ordering.
- Direct insert side mounted
- NSLS-1000
- Direct insert top mounted
- NTLS-1000
- Side Mounted Level Switch with External Chamber/Cage
- NSLS-2000
- Top Mounted Level Switch with External Chamber/Cage
- NTLS-2000
- NTLS-1000 length
- upto 2000 mm
