Tubular Level Gauge

The tubular level gauge provides direct liquid level readings for low pressure up to 25 bar and maximum temperature of 250 °C. Its glass is housed in a protective tube, and check balls in the upper and lower valves stop flow when the glass breaks.

Design features

• The gauge glass is built in the protective tube.
• Check balls inserted in the upper and lower valve to stop flow instantaneously when the glass is broken.
• The protector having a circular form is constructed to prevent glass breakage from external sources.
• Tubular glass with a linear red coating on the back is available to make level observation clearer.
• The manual adjustment of isolation valve at the input of the media entering the chamber reduces the bubbling.
• the body is made of forged material.
• The gauge has a relatively spacious internal area where foamy liquid is held from forming foams.
